uropathology cases

Lymphoepithelioma-like Urothelial Carcinoma of the Renal Pelvis - Report of a Case and Review of the Literature

Clinical History:

This 68 yrs old female was admitted to the out patient clinic with a two weeks history of macroscopic hematuria. On a intravenous pyelogram a large defect was present in the upper pelvis of the left kidney. A diagnosis of probable carcinoma of the pelvis was rendered and a total nephrourectectomy was done.


  • Fig. 1

  • Fig. 2

  • Fig. 3

  • Fig. 4

  • Fig. 5

  • Fig. 6

  • Fig. 7

  • Fig. 8

  • Fig. 9

Macro and Microscopic Description:

A large papillary tumor fills the upper pelvis (Fig 1.). Microscopic examination shows a carcinoma with large undifferentiated cells with a clear cytoplasm and ill defined cell borders, giving the tumor a syncytial appearance. A heavy lymphocytic infiltrate is present, (Fig. 2).

In other areas, the syncytial pattern was made of large eosinophylic deciduoid cells with a heavy leucocytic infiltrate (Figs. 3 and 4).

High grade urothelial carcinoma with pleomorphic nuclei and necrosis is present (Fig. 5). Unusual form of intrabular spread of the neoplastic urothelium into the collectings tubules is seen (Fig. 6).

Areas of the dysplastic urothelium are present adjacent to the tumor (Fig. 7). Cytokeratin staining with cytokeratin AE1/AE3 of the tumor cells is present (Fig. 8), as well as in the tumor located in the collecting tubules (Fig. 9).


Lymphoepithelioma-like Urothelial Carcinoma of the Renal Pelvis


Primary urothelial carcinoma of the upper urinary tract accounts for 7%-10% of all urothelial tumors. In the renal pelvis corresponds to 5% of all urothelial tumors (1-3).

The term lymphoepithelioma was coined in 1921 by Regaud and Schminke (4,5) to describe a tumor in the nasopharynx of Asian patients. This tumor characteristically is composed of cells with large nuclei and indistinct cell borders which impart a syncytial pattern to the tumor and it has an abundant lymphoplasmacytic inflammatory component that sometimes obscures the epithelial nature of the tumor. In this location there is a close pathogenetic link to Epstein-Barr virus (EBV) and EBV genomes have been indentified both by in situ hybridization and polymerase chain reaction.

With this phenotypic hallmark lymphoepithelioma-like carcinomas outside the nasopharynx were soon described. This included a variety of organs such as salivary gland (6), thymus (7), skin (8), stomach (9), lung (10), breast (11) and uterine cervix (12).

In the urinary tract the vast majority are located in the bladder (13-19). Sporadic cases in the urethra, the ureter and in the prostate gland (20, 21, 22, 23). In the renal pelvis only 8 cases had been reported (3,24, 29). In five of these cases, viral genome for EBV was tested with negative results.

Negative results for EBV-encoded RNA were found in a series of 28 cases of lymphoepithelioma-like carcinoma of the urinary tract reported by Tamas et al (26). This data confirm that EBV is not a pre-requisite for the development of lymphoepithelioma-like carcinoma phenotype in the urinary tract.

The unusual form of intratubular spread of the tumor into the collecting tubules in which the neoplastic urothelium lines and in some cases fill the lumina of these tubules without infiltration of the surrounding renal parenchyma is a rare pathological feature described in urothelial carcinomas of the renal pelvis and has been compared to the similar process of cancerization of ducts or lobules observed in breast carcinoma (3,30).


  1. Droller M J. Transitional Cell Carcinoma: Upper tracts and bladder, In: Walsh P C, Grittes R F, Perlmitter AD, Stamey TA (eds). Campbells Urology. WB Saunders: Philadelphia,1986 pp 1343-1440
  2. Olgac S, Mazumdar M, Dalbagni G, Reuter VE. Urothelial carcinoma of the renal pelvis: a clinicopathologic study of 130 cases. Am J Surg Pathol 2004;28.1545
  3. Perez-Montiel D, Wakely PE Jr,Hes O, Michal M, Swater S .High grade urothelial carcinoma of the renal pelvis. Mod Pathol 2006; 19: 494-503
  4. Regaud, Reverchon L. Sur un cas d epitheliome epidermoide developpe dans les massif maxillaure superieur. Rev Laringol Otol Rhinol .1921;42:369-378
  5. Schminke A. Uber lymphoepiteliale Geschwelste. Beitr Pathol Anat Allg Pathol 1921;68:161-170
  6. Kuo T, Hsueh C. Lymphoepithelioma-like salivary gland carcinoma in Taiwan: a clinicopathologic study of nine cases demonstrating a strong association with Epstein-Barr virus. Histopathology 1997; 31: 75-82
  7. Ritter JH,Wick MR. Primary carcinoma of the thymus gland . Sem Diagn Pathol 1999;16:18-31
  8. Leung EY, Yik YH, Chang JK. Lack of demonstrable EBV in Asian lymphoepithelioma-like carcinoma of the skin. Am J Surg Pathol 1995; 19:974-976
  9. Cho HJ, Kim JY, Yoo J, et al. Gastric carcinoma with lymphoid stroma. Incidence of EBV and Helicobacter pylori infection. Appl Imm Mol Morph 2003;11:149-152
  10. Butler AE, Colby TW,Weiss LM. Lymphoepithelioma-like carcinoma of the lung. Am J Surg Pathol 1989;13:629-632
  11. Sanati S, Ayala AG, Middleton LP. Lymphoepithelioma-like carcinoma of the breast: Report of a case mimicking lymphoma. Am Diag Pathol 2004;8: 309-315
  12. Martorell MA, Julian JM, Calabuig C, et al.Lymphoepithelioma-like carcinoma of the uterine cervix. Arch Pathol Lab Med 2002; 126: 1501-1505
  13. Amin MB, Ro JY, Lee KM, et al. Lymphoepithelioma-like carcinoma of the urinary bladder. Am J Surg Pathol 1994;18:466-473
  14. Holmang S, Borghede G, Johansson SL. Bladder Carcinoma with lymphoepithelioma-like differentiation: A report of nine cases. J Urol 1998;159: 779-782
  15. Chenk K, Chiang H, Fang C. EBER expression of pure urinary bladder lymphoepithelioma-like carcinoma into unique Asian patients. Urol Int 2005; 74:280-282
  16. Izquierdo- García FM, García-Diez F, Fernández I, et al. Lymphoepithelioma –like carcinoma of the bladder: Three cases with clinicopathologic and P53 protein expression study. Virchow Arch 2004;444: 420-425
  17. López-Beltrán A, Luque RJ, Vicioso L, et al. Lymphoepithelioma–like carcinoma of the urinary bladder: A clinicopathologic study of 13 cases. Virchow Arch 2001; 438:552-557
  18. Porcaro AB, Gilioli E Migliorini F, et al. Primary lymphoepithelioma –like carcinoma of the urinary bladder. Repor of one case with review and update of the literature after a pooled analysis of 43 patients. Int Urol Nephrol 2003; 35:99-106.
  19. Gulley ML, Amin MB, Nicholls JM, et al. Epstein-Barr virus is detected in undifferentiated nasopharyngeal carcinoma but not in lymphoepithelioma –like carcinoma of the urinary bladder. Hum Pathol 1995;26:1207-1213
  20. Terai A, Terada N, Ichioka K, Matsui Y, et al. lymphoepithelioma –like carcinoma of the ureter. Urology 2005;66: 1109
  21. Ma P, Leonard T, Trusell JC. Lymphoepithelioma of the ureter discovered intraoperatively during hysterectomy. Can J Urol 2008;15:4421-4424
  22. Allende DS, Desai M, Hansel DE. Primary lymphoepithelioma –like carcinoma of the ureter. Ann Diagn Pathol 2010; 14:209-214.
  23. López-Beltrán A, Cheng L, Prieto R, Blanca A, Montinori R. Lymphoepithelioma –like carcinoma of the prostate. Hum Pathol 2009; 40:982-987
  24. Fukunaga M, Ushigome S. lymphoepithelioma –like carcinoma of the renal pelvis: a case report with immunohistochemical analysis and in situ hybridization for the Epstein-Barr viral genome. Mod Pathol 1998;11:1252-1256
  25. Cohen RJ, Stanley JC, Dawkins HJS. lymphoepithelioma –like carcinoma of the renal pelvis. Pathology 1999;31:434-435
  26. Tamas EF, Nielsen ME, Schoenberg MP, Epstein JI. Lymphoepithelioma –like carcinoma of urinary tract: A clinicopathological study of 30 pure and mixed cases. Mod Pathol 2007;20:828-834
  27. Haga K, Aoyagi T, Kashiwazi A, et al. Lymphoepithelioma –like carcinoma of the renal pelvis. Int J Urol 2007; 14:851-853
  28. Yamada Y, Fujimura T, Yamaguchi T, et al. Lymphoepithelioma –like carcinoma of the renal pelvis. Int J Urol 2007;14:1093-1094
  29. Young UH, Sung JY, Young JS, et al. Lymphoepithelioma –like carcinoma of the renal pelvis. Korean J Irol 2008;49:461-463
  30. Fujimoto H, Tobisu KI, Sakamoto M, et al Intraductal tumor involvement and renal parenchymal invasion of transitional cell carcinoma in the renal pelvis. J Urol (Jap) 1995;153:57-60


Dr. Juan José Segura Fonseca, Laboratorio de Patología y Citología Diagnóstica, S.A., San José, Costa Rica

January 28th, 2011
